The WS8901B37 is a LoRa wireless data transmission radio designed and produced by Silent Smart Technology Co., Ltd. Its internal power amplifier ( PA) and low-noise amplifier ( LNA) improve transmit power and receive sensitivity, extending the communication range far beyond that of low-power 30 dBm radios. It supports an industrial-grade RS485 communication interface and features multiple protections, including reverse connection protection, overconnection protection, lightning protection, and antenna surge protection, enhancing its adaptability to complex environments.
The WS8901B37 operates within a 9V to 36V voltage range and can be configured via AT commands, facilitating user adaptation to diverse application scenarios. LoRa's direct-sequence spread spectrum technology, with its concentrated power density, offers longer range and improved anti-interference capabilities. The WS8901B37 radio includes a serial port and SWD download interface, allowing for user development (we can customize standard LoRaWan and Alibaba LinkWan nodes).
Supports 230MHz power band. Better penetration and bypass capability compared to 433MHz band
Supports LoRa modulation
With LoRa modulation ASR6601CB has a sensitivity of up to -148dBm and a maximum transmit power of 37dBm (5W).
Supports up to 62.5kbps airspeed with LoRa modulation.
Support RS485, using the original imported core, stable, reliable, adaptable
Multiple protections such as power supply anti-reverse connection, power supply over-voltage protection, lightning anti-surge protection, antenna surge protection, etc.
Industrial-grade standard design, support -40 ~ +85 ℃ long time use
Wide voltage range: 9V~36V
Ultra-small size 82x62x25mm design, users can be developed twice.
